8 port long range uhf rfid reader

FOB Reference Price:Get Latest Price
US $500-650 / Pieces | 1 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
Vanch
Model Number:
VF-787
Material:
ABS
Product Name:
8 port long range uhf rfid reader
Power supply:
AC adapter 220V input
Interface:
RS232/RS485/TCP IP/Wiegand
Frequency:
865-868/902-928mhz
Read range:
2-15m
Protocol:
ISO18000-6C/EPCG2
Application:
rfid warehouse management system, access control system etc.
Color:
Black/White
SDK:
C#, C++, JAVA etc.
Supply Ability
Supply Ability:
300 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
Standard carton box for package
Port
shenzhen
Lead Time :
3-5 days after payment received

8 port long range uhf rfid reader

Product Description



Shell adopt high strength die-casting aluminum, highlighting the product quality

Adopt high-performance Impinj UHF reader chip IndyR2000,the best Intensive reader mode,the maximum read speed and optimum read ranges.

Application: logistics supply chain,fixed asset management and library and archive management etc.


Specification



Model

VF-787



Performance Index

Frequency range

860-868MHZ, 902-928MHZ(can be customized)

Frequency modulation

FHSS or fixed-frequency,  can be set by software

RF output

+10.0 to +32.5 dBm; 50 ohm load.

The number of antennas

8 SMA antenna connectors for selections

Communication interface

10M/100MAdaptive Ethernet, RS232, RS485, Wiegand26/34 interface

Communication rate

Serial rate 9600~115200bps, RJ45 is 10Mbps

Secure firmware upgrade

The upgrade mechanism can be extended

input / output (GPIO)

2 inputs, 1 output

Certifications

CE/FCC

Application software

Supply API SDK and VC and VB, Delphi application routines

Tag Operation Performance

Reading distance

8dbi Antenna configuration, typical read range: 3 to 25 m (depends on tag)

Protocol

EPC global UHF Class 1 Gen 2 / ISO 18000-6C/ ISO18000-6B

Maximum receiver sensitivity

-82 dBm; Maximum return loss: 10 DBm

Mechanical electrical performance

Dimension

200 (L) * 200 (W) * 35 (H) mm

Power

With 220V AC input, the output of +12 V/3A DC power converter, and the power consumption is below 1W.

Weight

1.1KG

Humidity

5% to 95%, Non-condensing

IP rating

IEC IP51

Operating Temp.

-20 ºC to +60  ºC

Storage Temp.

-40°C to 80°C





Application

 The 8 ports long range uhf rfid reader VF-787 could be used for rfid warehouse management system, RFID access control system, rfid asset tracking system etc.

747 w.jpgVF-747 A.jpg



Vanch projects

Not only for this, we did some other related projects as well, pls check the project pictures.

Welcome to contact me at mail beata at vanch.net if you have any interest!

88T.jpganimal tracking 7.jpgTire tracking.jpg
