UHF long range rfid reader rj45 support ISO18000-6C protocol can use for parking system

FOB Reference Price:Get Latest Price
US $210-250 / Sets | 1 Set/Sets Long range rfid reader (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
VANCH
Model Number:
VI-86F
Frequency:
902-928/ 865-868MHz(or customized)
Read range:
5 to 6 m (depends on tag)
Dbi:
9dBI
Protection grade:
IEC IP54.
Dimension:
306*306*25mm
RF output:
30dBm adjustable;50Ω load
Operation temperature:
-20 to +60 centigrade degree
Communication interface:
LAN,RS232,RS485,Wiegand26/34,IEEE 802.11
Software:
Provide with API SDK and VC, VB, Java
Application:
Vehicle Control, Parking System,Animal Management
Supply Ability
Supply Ability:
1000 Unit/Units per Month long range rfid reader
Packaging & Delivery
Packaging Details
1pcs/paper box caton
Port
shenzhen ,guangdong
Lead Time :
3-5 work day after receipt payment

UHF long range rfid reader rj45 support ISO18000-6C protocol can use for parking system

Product Description
Application: logistics, access control, parking management, manufacturing control and etc.



Features:

1. Reliable industry structure design, workable in varied severe environment.

2. Parking management: Long range intelligent parking management and automatic charge without stop the car

3. Production line management: Goods identification for production flow

4. Auto Access control: Long range access control management for custom, sea port

5. Logistics and warehouse management

6. People auto registry for important meeting or exhibition



7. Automatic weighing and data capture.







Specification

UHF long range rfid reader rj45 support ISO18000-6C(EPC GEN2) protocol can use for parking system

Model#

VI-86F



Performance Index

Frequency range

902-928MHZ/865-868MHz(or customized)

FM mode

FHSS or fixed frequency, set by the software

RF output

30dBm adjustable;50Ω load

Communication interface

LAN,RS232,RS485,Wiegand26/34,IEEE 802.11

Communication rate

Serial port 9600~115200bps,RJ45 10Mbps

GP I/O interface

12 pin + 4 pin

Power dissipation

average<10W

Application software

Provide with API SDK and VC, VB, Java application routines

Tag Operation Performance

Reading distance

5~8m equipped with 9dbi antenna(tag dependent)

Air interface

EPC global UHF ISO-18000-6C(EPC G2), ISO-18000-6B

Mechanical and Electrical Performance

Dimension

306(L)*306(W)*25(H)mm(excluding mounting bracket and external wiring)

Power supply

Equipped with power convertor 220V AC input, +9V/3A DC output

Weight

2.6Kg

Installation

Embrace rod mounting

Diameter of support rod

40-50mm

Humidity

5% to 95%, non-condensing

Protection grade

IEC IP54

Operation temperature

-20 ºC to +60  ºC







UHF long range rfid reader rj45 support ISO18000-6C(EPC GEN2) protocol can use for parking system

UHF long range rfid reader rj45 support ISO18000-6C(EPC GEN2) protocol can use for parking system



RFID Application

We offer RFID reader and RFID tags,RFID labels in different application



1.Warehouse management solution

(Apparel warehouse/shoes warehouse/supermarket...)

UHF long range rfid reader rj45 support ISO18000-6C(EPC GEN2) protocol can use for parking system

2.Assets management solution

(jewellery/tablets/cumputers/books/files/tyer/trunk/guns.....)

UHF long range rfid reader rj45 support ISO18000-6C(EPC GEN2) protocol can use for parking system

3.Retail store management solution

UHF long range rfid reader rj45 support ISO18000-6C(EPC GEN2) protocol can use for parking system

4.Goods inventory solution

5. People punch clock solution

Applications
 UHF long range rfid reader rj45 support ISO18000-6C(EPC GEN2) protocol can use for parking system
UHF long range rfid reader rj45 support ISO18000-6C(EPC GEN2) protocol can use for parking system
UHF long range rfid reader rj45 support ISO18000-6C(EPC GEN2) protocol can use for parking system
UHF long range rfid reader rj45 support ISO18000-6C(EPC GEN2) protocol can use for parking system
UHF long range rfid reader rj45 support ISO18000-6C(EPC GEN2) protocol can use for parking system
UHF long range rfid reader rj45 support ISO18000-6C(EPC GEN2) protocol can use for parking system

FAQ

1, Q:Who are we?

    A:We are a leading Chinese professional UHF RFID Hardware manufacturer with more than 10 years. We are located in Shenzhen, a city near to HongKong.



2, Q: What products do you manufacture?

    A: we can be able to manufacture all kinds of UHF RFID reader, antenna and tag (comply the protocol of EPC C1G2  and ISO-18000/6C).  we can help you customize all kinds of reader, antenna and tag.



3, Q: What are your advantages?

    A: we have many advantages.

     Firstly, we have been focusing on R&D, productions, sales and implementation of UHF RFID reader, UHF RFID antenna and UHF RFID Tag for more than 10 years.

     Secondly, we are good at designing all kinds of RFID solution for different industries or applications.

     Thirdly, our products has been sold to all over the world, they are serving for government, big retailer, school, big manufacturing company and logistic company as well as vehicle managmenent/transportation etc.

     Fourth, we have own professional staffs in RFID, no matter what production, research or engineer or sales.



4, Q: What are your client type?

    A: As a RFID hardware manufacturer, we usualy work with system integrator, solution provider or IT software company directly because we can supply hardware to them and they can develop software and implement/install/integrate hardware and software for their end-user directly.



5, Q: If I want to buy your products, what should we do first?

    A: as RFID product is complex system (need further development), so you need to tell us your project requirement, for example,

what is the tracked item?

                       What is the reading distance required?

                       What type of reader do you want to use on your project?

Fixed reader or handheld reader?

After we are clear your requiements, we will send you datasheet and quotation for your reference.

 After confirming well, we will send you PI for paying fund to us and then we will send you goods ASAP once we got your payment already.



6, Q: What certficate do your products have?

    A: our products have CE and FCC certificates.



If you want to learn more,pls visit our youtube link: ( Skype:andyzhou60 )



https://www.youtube.com/channel/UCdS1Mz5518WNoQh5tAjiwzA/videos?shelf_id=0&view=0&sort=dd

UHF long range rfid reader rj45 support ISO18000-6C(EPC GEN2) protocol can use for parking system
